DJI Zenmuse V1 Speaker

DJI Zenmuse V1 Speaker

  • Powerful sound output generates 129 decibels at one meter distance.
  • Clear audio broadcasts reach ground targets up to 700 meters away.
  • Real-time broadcasting via Pilot 2 is supported exclusively on Matrice 400.
  • Advanced text to speech functionality supports multiple international language options.
  • Directional audio pickup on RC Plus effectively filters out environmental noise.
  • Single axis gimbal provides controllable tilt for precise directional acoustic broadcasting.
  • Rugged IP54 rating ensures reliable operation in dusty or damp environments.
  • Lightweight design weighs only 1.52 pounds for multi-payload configuration flexibility.
  • Intelligent volume adjustment utilizes automatic gain control for clear audio levels.
Request Wholesale

Specs

Zenmuse V1

  • Product name: Zenmuse V1
  • Weight: 690 ±10 g
  • Dimensions: 134 × 119 × 140 mm (L × W × H)
  • Rated power: 30 W
  • Supported aircraft: Matrice 400, Matrice 350 RTK, Matrice 300 RTK (requires DJI RC Plus)
  • Shell temperature: <50°C (122°F)
  • Ingress protection rating: IP54
  • Operating temperature: -20°C to 50°C (-4°F to 122°F)
  • Storage temperature: -20°C to 60°C (-4°F to 140°F)

Gimbal System

  • Stabilization: Single-axis (tilt)
  • Angular vibration range: ±0.01° (hover), ±0.02° (flight)
  • Mounting: Detachable DJI SKYPORT
  • Mechanical range: Tilt -125° to +25°
  • Controllable range (Matrice 400 downward ports): -120° to -5°
  • Controllable range (Matrice 400 third underside port): -60° to 0°
  • Controllable range (M300/M350 downward ports): -120° to -5°
  • Controllable range (M300/M350 upward port): -5° to +120°
  • Operation modes: Follow, Free, Re-center

Audio Performance

  • Impedance: 4 Ω
  • Nominal power: 25 W
  • Effective broadcast distance: 700 m (Matrice 400), 500 m (M300/M350)
  • Max sound pressure level: 129 dB @1 m (M400), 127 dB @1 m (M300/M350)
  • Effective bandwidth: 800 Hz – 8 kHz

Broadcast & Playback Functions

  • Recording and playback supported
  • Real-time broadcasting: Matrice 400 only
  • Text-to-speech languages (M400): Chinese, English, Spanish, Korean, Japanese, French
  • Text-to-speech languages (M300/M350): Chinese, English
  • Audio file formats: MP3, AAC, WAV
  • Simultaneous file transfer and playback supported on Matrice 400
  • Playback control: Record, stop, loop, volume adjustment
  • Custom controller button recording trigger supported
  • Gimbal synchronization with other payloads supported

Intelligent Features & Protection

  • Automatic gain control adjusts recording volume (Matrice 400)
  • Directional audio pickup with environmental noise reduction
  • Speaker temperature, overcurrent, and power protection
  • Directional broadcasting visualization via DJI Pilot 2 AR projection

Packaging

(1) Zenmuse V1 Loudspeaker Payload
(1) Gimbal Port Protection Cap
(1) Storage Box
(1) Manuals

View full details

DJI Enterprise Drone Dealer in the USA

Remote Communication & Announcements

  • A high-powered aerial speaker that can broadcast clear voice messages from the drone in real-time.
  • Enables communication over large areas or hard-to-reach locations without on-site personnel.
  • Applications: Emergency instructions, public announcements, crowd control, and disaster response communications.

Public Safety & Emergency Response

  • Works alongside drones equipped with cameras or thermal sensors to coordinate emergency operations.
  • Facilitates live guidance, warnings, or instructions in hazardous or remote environments.
  • Applications: Search & rescue operations, firefighting, evacuation guidance, and disaster management.

Security & Law Enforcement

  • Provides real-time aerial communication during security patrols or monitoring events.
  • Enhances crowd management, perimeter control, and enforcement operations with direct audible instructions.
  • Applications: Nighttime security patrols, event monitoring, industrial site protection, and perimeter enforcement.

Versatile Enterprise Applications

  • Designed for public safety, law enforcement, security, and industrial monitoring.
  • Drone-compatible and remotely controllable, enabling rapid deployment in urban, industrial, or remote areas.
  • Applications: Emergency response coordination, industrial site alerts, remote crowd management, and large-area messaging.
